Tolerance is a virtue. Integrated Free Standing Bean to cup coffee vending machine with ice maker. (Visual design of fresh grinding, Automatic cup lid dispenser, built-in ice making unit, BIB interface).

Hot drink & Iced drink vending machine 2in1-- JL500I-ESFB5C2B-PI


Jetinno JL500I-ESFB5C2B-PI , the iced drink vending machine , is a wodenrful option for public places. With compacted design, the machine is combined with coffee & tea vending machine + water chiller + ice maker. It can do more than 20 hot and iced drinks. This iced coffee vending machine is a fantastic choice for hot summer.


ice drink vending machine

Feature

coffee vending                                           coffee vending machine

  Visual design of freshly grinding                                                        Automatic cup lid dispenser


coffee vending machine                                            coffee machine

Built-in ice making unit                                                                                liquid juice interface


Product details

40 hot and cold beverages. A drink station for all seasons.

  • Cold or hot coffee optional

  • Built-in ice machine to chill the summer down


Not only bean to cup coffee, but also BIB concentrated jam

  • BIB interface, restore the great flavor of fruits.

  • Ditting grinder + high-pressure espresso coffee brewer to extract an espresso with rich cream and intense aroma.


Take it and go

  • Fully automatic production to make a coffee with 45 seconds

  • Automatic cup dispenser+ automatic cup lid dispenser, more intimate


Intimate design can be felt

  • Self-propelled stirring rod device, stirring coffee and it will be more delicious

  • Sutomatic cup lifting door, more convenience to take a coffee

  • Visual design of coffee bean hopper and grinder, a bean to cup coffee can be seen.



Built-in automatic cup dispenser module

  • Intelligent cup lid dispenser and automatic lid dropped out

  • Automatic detection at cup holder to prevent repeated drop of cup lid

  • Cup lid dispenser with touch screen, more intelligent and friendly use


BIB interface module

  • Peristaltic pump with precise-output control to ensure the standardization of each cup

  • Sanitary environment ensured by regular cleaning of the sources tube’

  • Removable design for easier cleaning


Specification

Moule numberJL500I-ESFB5C2B-PI

 Weight:

 290kg

 Dimension:

 1000(W)*785(D)*1855(H)mm

 OS:

 Linux / Android

 Maximum power:

 2700W

 Life Span:

 125,000 cycles

 Screen:

 27 inch touch screen

Production rate

Espresso 45sec(30ml), Instant drinks 25sec (120ml), Hot water 15ml/s

coffee grinder

Ditting professional grinder

Hydraulic system

700ml stainless steel boiler + gear pump instant pressure system + cold water

system + built-in ice machine unit

Brewer system

High pressure coffee brewer + Mixter + low pressure brewer + Low pressure

tea brewer

Raw material module

coffee bean hopper (4L*1) + instnat canisters (4L*6)

Water supply

Water pump/ tap water

Payment system

QR code/bill validator/cashless system/coin accptor/RFID card (optional)

Color

Black (customized)

Certificates

CE/CB/CQC (all parts connecting to drnks meet LFGB standard)

 Network:

 Wifi, 4G(optional)


DIY of the vending page

It is available to change picutures of background, logo and drink anytime by yourself just with a computer and a flash-drive

vending machine


Remote Monitor

With Jetinno cloud server, it is available for you to check the sales data and machine status on your computert or mobile phone anytime

72f41163c92a24d60bc60894d78f54b



phone page

vending machine        vending machine


computer page

vending machine

vending machine


Application Location

public places like shopping mall, school, university, train station, metro station, airport etc.

coffee machine

ice drink vending Machine


Certificates

CE/CB/CQC/ISO

jetinno coffee equipment


Company

Jetinno was built in 2013.Before that,all the members in founding team used to work in a well known German commercial coffee machine company for nearly 10 years.They had accumulated rich R&D experience and market knowledge in developing machines meeting the demand globally.To become the No.1 coffee equipment and overall solution provider is the aim of Jetinno. Jetinno introduces R&D model of IOT+Platform+Technology, and is commited to manufacturing world class coffee equipment,creating access to charm of technology and innovation for more people, improving the quality of more people's life.
